M228 STEREO POWER AMPLIFIER
M228 STEREO POWER AMPLIFIER
True dual mono architecture: Two fully independent amplifier channels housed within a single chassis, preserving isolation, channel separation, and stereo integrity
High current, high power performance: Effortless delivery of substantial current to maintain control and composure with even the most demanding loudspeakers
Advanced linear power supplies: Dedicated high-current power delivery per channel ensures consistency, stability, and dynamic authority across complex musical passages
Fully balanced signal path: Dual differential, internally balanced design minimises noise and distortion while maximising clarity, resolution, and musical realism
Finish available in Classic black, Argento silver, and Platinum
The M228 Stereo Power Amplifier distils the essence of the M28 monoblocks into a refined, compact single-chassis design. Crafted as a pure, precisely controlled current source, it combines authority with finesse, delivering an immediate, immersive listening experience that remains composed, powerful, and engaging at all levels.
TWO MONOBLOCKS
ONE CHASSIS
The Bricasti M228 stereo amplifier was designed to deliver, within a single chassis, the same performance as two M28 mono amplifiers, with no compromise. It offers an exceptionally pure and precisely controlled current reserve. The handcrafted expression embodied in this deep cabinet effortlessly delivers the immense current required to drive and control any loudspeaker through the most demanding musical passages. The sought-after and often elusive listening experience is immediately apparent.
The M228 is conservatively rated at 200 watts per channel into an 8-ohm load, with a flat frequency response and negligible distortion, as expected. Low-frequency performance is fast and articulate, even at the loudspeaker’s resonance peak.
TWING FORCES
ONE PRESENCE
A completely balanced differential design reduces stress on all internal parts of the M228 amplifier. When combined with the balanced layout of the Bricasti digital-to-analog converters, the M228 establishes a fully balanced differential signal path from source to loudspeaker. This distinctive pair forms an optimized, engineered system that delivers effortless, natural sound quality, experienced even at high volumes.
BEAUTIFULLY BUILT
BY DESIGN
Harmony of concept and function, the M228 amplifier reflects the precision and beauty of a meticulously engineered system. The machined aluminum chassis is sculpted to exacting tolerances, and each electronic component is placed in a purpose-designed location within the enclosure. Careful attention to grounding and passive ventilation ensures even heat distribution and a cool-to-the-touch exterior under any operating load.
FEATURES
FULLY DIFFERENTIAL
TECHNOLOGY
The M228 stereo amplifier features a fully balanced, dual mono design with separate amplifiers for each channel, delivering exceptional signal fidelity. Preventing negative signals from contacting ground reduces crosstalk, noise, and interference, improving the signal-to-noise ratio for a more natural, lifelike sound at any volume.
Handcrafted in the USA
All of our products are crafted in the old world tradition, in a classic brick mill building in Massachusetts USA by a team of individuals dedicated to excellence.
M228 TECHNICAL SPECIFICATIONS
TOTAL HARMONIC DISTORTION:
THD+N less than 0.005% 20hz-20kHz at full rated power into 8 and 4 ohms.
POWER:
200W into 8 ohms, 400W into 4 ohms, 800W into 2 ohms.
FREQUENCY RESPONSE:
10hz-150kHz, within 0.5db.
SIGNAL TO NOISE:
Greater than 95db at full rated power.
POWER TOPOLOGY:
Fully Differential, bi polar.
BALANCED INPUT:
XLR connector 200k ohm impedance.
GENERAL SPECIFICATIONS
GENERAL SPECIFICATIONS:
EMC: Complies: EN 55103-1, EN 55103-2, FCC part 15 and Class B
ROHS:
Complies with: EU RoHS Directive 2002/95/EC
SAFETY:
Certified to: IEC 60065, EN 55103-2
OPERATING TEMPERATURE:
32 F to 105 F (0 C to 40 C)
STORAGE TEMPERATURE:
-22 f to 167 F (-30 C to 70 C)
FINISH OPTIONS:
DIMENSIONS:
15” x 17“ x 18”
38.1, 43.18 45.72 cm
WEIGHT:
121.25lbs, 55 kg
MAINS VOLTAGE:
-100, 120, 220, 240 VAC, 50 Hz – 60 Hz factory set
TRIGGER IN:
TRS connector for 5V external trigger on ring.
POWER CONSUMPTION:
60 Watts Standby, 2W idle
WARRANTY PARTS AND LABOUR:
5 years
