M32 MONOBLOCK POWER AMPLIFIER
M32 MONOBLOCK POWER AMPLIFIER
Flagship design: The M32 represents Bricasti’s highest level of audio engineering, embodying a commitment to sound precision and uncompromising build quality
Enhanced transformer technology: Proprietary, high-grade transformers are designed to reduce noise, maintain signal purity, and deliver exceptional current on demand
Fully differential architecture: Balanced circuitry for each channel enhances dynamic range and detail while minimizing distortion
Precision-tuned power supply: An ultra-stable, low-noise power supply optimized for high power output and consistent performance at all listening levels
Crafted for sonic transparency: Built with carefully matched components, internal isolation, and vibration-damping features to deliver a lifelike, uncompromised musical experience
Finish available in Classic black, Argento silver, and Platinum
The M32 Monoblock Amplifier is the latest evolution in Bricasti’s line of power amplifiers. Building upon the already impressive M30, the flagship M32 raises the bar with remarkable depth, solidity, and musicality that must be experienced to be fully appreciated.
SUPERCHARGED
CURRENT
The M32 delivers an impressive 50% increase in current over the M30 Monoblock amplifier, offering high current output, extremely low noise and distortion, and even lower power supply ripple. Power delivery is rated at 250W into 8 ohms, 500W into 4 ohms, and current-limited for safety at 1000W into 2 ohms—with peak power exceeding 1kW into 4 ohms.
FULLY
DIFFERENTIAL
Not all audio devices offer balanced end-to-end performance. The M32 features a fully differential design that delivers a fast, low-distortion, and harmonically accurate musical experience. When paired with any of Bricasti’s fully differential digital-to-analog converters, it enables a truly balanced system from source to speaker.
DIALED-IN
DESIGN
The improved chassis is designed to accommodate a larger, custom-made power transformer, allowing for greater separation between the power components and the voltage and current gain sections of the amplifier. This layout results in exceptionally low noise performance, effectively eliminating any practical interference between the power supply and the amplifier’s gain stages.
FEATURES
FULLY DIFFERENTIAL
TECHNOLOGY
The M32 monoblock amplifier features a fully balanced, dual mono design with separate amplifiers for each channel, delivering exceptional signal fidelity. Preventing negative signals from contacting ground reduces crosstalk, noise, and interference, improving the signal-to-noise ratio for a more natural, lifelike sound at any volume.
Handcrafted in the USA
All of our products are crafted in the old world tradition, in a classic brick mill building in Massachusetts USA by a team of individuals dedicated to excellence.
M32 TECHNICAL SPECIFICATIONS
TOTAL HARMONIC DISTORTION:
THD+N less than 0.005% 20hz-20kHz at full rated power into 8 and 4 ohms.
POWER:
250W into 8 ohms, 500W into 4 ohms, 1000W into 2 ohms.
FREQUENCY RESPONSE:
10hz-150kHz, within 0.5db.
SIGNAL TO NOISE:
Greater than 85db at full rated power.
POWER TOPOLOGY:
Fully Differential, bi polar.
BALANCED INPUT:
XLR connector 200k ohm impedance.
GENERAL SPECIFICATIONS
GENERAL SPECIFICATIONS:
EMC: Complies: EN 55103-1, EN 55103-2, FCC part 15 and Class B
ROHS:
Complies with: EU RoHS Directive 2002/95/EC
SAFETY:
Certified to: IEC 60065, EN 55103-2
OPERATING TEMPERATURE:
32 F to 105 F (0 C to 40 C)
STORAGE TEMPERATURE:
-22 f to 167 F (-30 C to 70 C)
FINISH OPTIONS:
DIMENSIONS:
15” x 17“ x 18”
38.1, 43.18 45.72 cm
WEIGHT:
121.25lbs, 55 kg
MAINS VOLTAGE:
-100, 120, 220, 240 VAC, 50 Hz – 60 Hz factory set
TRIGGER IN:
TRS connector for 5V external trigger on ring.
POWER CONSUMPTION:
60 Watts Standby, 2W idle
WARRANTY PARTS AND LABOUR:
5 years
